Nominal voltage 12 V

Float charge 2,27 V/C @ 25 °C

Capacity CP 10min 1,6V/C 25°C 4305W/Bloc CC 10h 1,8V/C 25°C 120Ah

Terminal F - M6

Terminal Torque 11 Nm

Container UL 94 HB ?Polypropylene?

Temperature range -40°C to 55°C

Dimensions ?l x b/w x h? 351 x 172 x 291 mm

Weight 43,6 kg

Origin Castanheira, Portugal

Preliminary technical data sheet

Technical features:

• Design life: >12 years at 20 °C (until 80% nominal C10)

• Maintenance-free (no topping up) during the whole service life

• High-compression Absorbent Glass Mat (AGM) technology

• Power (10 minutes) from 1978 to 5006 watt

• Standard or flame-retardant version (UL 94 V-0)

• Pure Lead

• Very low gassing due to internal gas recombination (99% efficiency)

Standards & certifications:

• EUROBAT 2015 classification:

>12 years – Very Long life

• No restrictions for rail, road, sea, and air transportation (IATA, DGR clause A67) – trouble-free transportation of operational blocks

• Approval: UL (Underwriters Laboratories)

• Designed in accordance with IEC 60896-21/22

• Manufactured in Europe in our ISO 9001 certified production plants

Design life Nominal capacity Block battery Grid plate Recyclable Valve regulated Maintenance free Special high

>12 years – 56.4-195 Ah lead-acid (no topping up) current

very long life
